HMPE/Polyester Double Braid Crane Slings 5/8"
These double braid slings are constructed with an HMPE (aka Dyneema) 12 strand core and a polyester cover. The cover offers great heat and snag resistance as well as enhances the grip while keeping the 12 strand core protected. The 12 strand core maintains lightweight construction, high strength and low stretch.
Specifications
- MBS (Basket)
- 5.4 t
- Material
- HMPE/Polyester
- WLL - Straight (Label)
- 2.7 t
- WLL - Choker Hitch
- 2.16 t
- MBS (Label)
- 13.5 t
- MBS Imperial
- 27000 lbf
- MBS Metric
- 120 kN
- Width
- 5/8 in
- Colour
- Blue, Red, Blue/Red
- Diameter
- 5/8 in
- Length
- 20, 18, 35, 25, 30, 15 ft
- Break Strength
- 29000 lbf
- Weight
- 16.5 lb
- MBS (Choked)
- 2.16 t
- Max Lifespan from date of Manufacture
- 10 years
- WLL - Basket Hitch (Vertical)
- 5.4 t
Available in 7 variants
